JM-2100 / 2200xxx Series
JM-2100 / 2200 series is high RF power customized jammer in carry case. Developed according to special customer's request, the output power of each band could be up to 40W, and effective blocking range can reach hundreds of meters. It is built in pelican case, easy to carry, camouflaged, and raining-proofed.
Specification
| Frequency synthesizes | PLL |
| Frequency & Output power (depend on requested) | 851/869 ~ 894 MHz, EIRP 8W ~ 40W |
| 925/936 ~ 965 MHz, EIRP 8W ~ 40W | |
| 1800 ~ 1990 MHz, EIRP 8W ~ 40W | |
| 2110 ~ 2170 MHz, EIRP 8W – 40W | |
| 20~100 MHz, EIRP 20W – 60W | |
| 100 ~ 500 MHz, EIRP 20W ~ 60W | |
| Effective range | 50~100 meter distance |
| Antenna | Built in Patch Antenna or Omni antenna |
| Heating ventilation | Well designed |
| Inner housing | Special design rigid of inner aluminum housing |
| Battery | Lithium battery, can support 1 ~ 2 hours operating |
| Power adaptor Input Voltage | AC100V ~ 250V, 50Hz ~ 60Hz |
| Dimension | Depend on the request |
| Weight | 15 ~ 45Kgs (System + Battery) |
| Warranty | One year |
